Features
Htst pasteurization equipment for sale introduction:
Htst mean High Temperature Short Time. Ultra-high temperature sterilization machine can use ultra-high temperature to complete the sterilization work in a short time. Ultra-high temperature short-term sterilization can protect food taste as much as possible under the work of sterilization.The sterilization process of the tubular ultra-high temperature sterilizer can not only be used for general products, but also can meet the special needs of customers, such as: long-term production of products with particles, medium and high viscosity products, such as cream, pure milk, and multiple products (milk , Fruit juice, cream) products with high viscosity; products with larger fiber and pulp particles; higher acidity; products that are corrosive to dead ends. Sterilize products at 120~140℃ high temperature and ultra-high temperature.
Ultra high temperature milk pasteurizing machine:
It has the characteristics of high heat recovery rate, compact and beautiful structure, and stable temperature control.Control mode: semi-automatic control, fully automatic control (PLC control, touch screen display)
The system adopts a high-temperature treatment method to achieve strict sterilization of liquid dairy products, tea beverages, juices, etc., and then transfer them into aseptic packaging. The sterilization temperature is 135~140℃, and the heat preservation time is only 4~5 seconds. It is possible to maintain the original nutritious color and flavor of beverage dairy products.
Technical Data
Name | GGTG-7-1.6-35 | GGTG-7-1.6-45 | GGTG-7-1.6-58 | GGTG-7-1.6-72 | |
Production capacity | t/h | 2 | 3 | 4 | 5 |
Heat exchanging area | m2 | 35 | 45 | 58 | 72 |
Temperature of material inlet | ℃ | 5 | 5 | 5 | 5 |
Temperature of material outlet | ℃ | 25 | 25 | 25 | 25 |
Sterilizing temperature | ℃ | 95-137 | 95-137 | 95-137 | 95-137 |
Heat preservation period | S | 15-4 | 15-4 | 15-4 | 15-4 |
Ice water consumption | multiple | 3 | 3 | 3 | 3 |
Cooling water consumption | multiple | 2 | 2 | 2 | 2 |
Energy consumption | kw | 10 | 10 | 12 | 14 |
Outline dimensions | mm | 4500*1900*1880 | 4500*1900*1880 | 4500*1900*1880 | 6500*2000*1880 |
